QNAP TS-h1073BXeU-RP-8G

TS-h1073BXeU-8G-RP

CPU
AMD Ryzen™ Embedded V1780B 4-core/8-thread processor 3.235 GHz

CPU architecture
64-bit x86

Encryption engine
Yes (AES-NI)

Hardware-accelerated transcoding
Optional via PCIe graphics card

System memory
8 GB SODIMM DDR4

Maximum memory
64 GB (2 x 32 GB)

Memory slot
2 x SODIMM DDR4

ECC memory support
For a dual-DIMM configuration, you must use a pair of identical DDR4 modules.

Flash memory
5 GB (OS dual-boot protection)

Drive bays
8 x 3.5-inch SATA 6Gb/s, 3Gb/s

The system ships without HDDs.

Drive compatibility
3.5-inch SATA hard disk drives
2.5-inch SATA SSDs
E1.S NVMe SSDs

Hot-swap
Yes

M.2 slot
Optional via M.2 adapter

If a heatsink is to be installed, it is recommended that the dimensions of the top heatsink be smaller than 68 x 20 x 10 mm (D x W x H)

SSD cache acceleration support
Yes

Gigabit Ethernet ports (RJ45)
4
Expandable with optional PCIe adapter

2.5-Gigabit Ethernet ports (2.5G/1G/100M)
2 (2.5G/1G/100M/10M)

5-Gigabit Ethernet port (5G/2.5G/1G/100M)
Optional via network adapter

10-Gigabit Ethernet ports
2 x 10GbE SFP+

Wake on LAN (WOL)
Yes

Jumbo Frame
Yes

PCIe slot
1 x PCIe Gen 3 x4

PCIe slot card dimensions
190 x 68.9 x 18.76 mm

USB 3.2 Gen 2 ports (10Gbps)
1 x Type-C
2 x Type-A

HDMI™ output
Optional via PCIe graphics card

Form factor
2U rack-mount

LED indicators
HDD 1-8, Status, LAN, USB, Power, E1.S 1-2

Buttons
Power, reset

Dimensions (H x W x D)
88.6 × 432 × 294.9 mm
Excludes the hook and protruding part of the power supply unit.

Operating temperature
0 – 40 °C (32 – 104 °F)

Storage temperature
-20 – 70 °C (-4 – 158 °F)

Relative humidity
5 to 95% RH, non-condensing, wet-bulb temperature: 27 °C (80.6 °F)

Power supply unit
350 W (x2) power supply, 100 - 240 V

Power consumption: operating mode, typical
212.12 W

Fan
4 x 50 mm, 12 V DC

System warning
Buzzer

Standard warranty
3 years

Max. number of concurrent connections (CIFS) – with max. memory
2000
