ASRock MB Sc AM5 X870 LiveMixer WiFi, AMD X870, 4xDDR5, 1xHDMI, 2xUSB4, WI-FI, ATX

ASROCK X870 LiveMixer WiFi
LiveMixer is designed through current-gen content creators, who need motherboards with great connectivity for streaming and other auxiliary devices. Also, its reliable performance allows us to provide wonderful contents and budget our time.
Unique Feature
Superb Productivity

• PCIe Gen5 (Graphics, M.2)
• Dual Channel DDR5
  Rock-Solid Durability
• 16+2+1 Power Phase, 80A Dr.MOS for VCore+SOC+MISC with Enlarged Heatsink Armor
• Flexible Integrated I/O Shield
• 20K Long-lasting Black Caps (high quality and conductive polymer capacitors) for VCore
  Ultrafast Connectivity
• 5G LAN, 802.11be Wi-Fi 7 Module
• ASRock Lightning Gaming Ports
  EZ Update
• BIOS Flashback Button
• ASRock Auto Driver Installer
  EZ Troubleshooter
• ASRock Post Status Checker
  CPU
• Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*

• The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details.
  Chipset

• AMD X870
  Memory
• Dual Channel DDR5 Memory Technology
• 4 x DDR5 DIMM Expansion Slots
• Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)*
• Max. capacity of system memory: 256GB
• Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules*
  *Please refer to Memory Support List on ASRock's website for more information.
  BIOS
• 256Mb AMI UEFI Legal BIOS with GUI support
  Graphics
  Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
• 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
• 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz** Only the CPU's embedded graphics can be displayed through USB4 ports. If you want to display to a Type-C monitor, please use AM5 Ryzen™ 9000, 8000 and 7000 processors with embedded graphics.* USB4 controller(for USB4_TC1 and USB4_TC2) will run at Gen4x2 with with 8000 (Phoenix 2) series processors.

Audio

• 7.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)
• Individual PCB Layers for R/L Audio Channel
• Nahimic Audio
  LAN
• 5 Gigabit LAN 10/100/1000/2500/5000 Mb/s
• Realtek RTL8126
  Wireless Communication module
• 802.11be 2x2 Wi-Fi 7 Module
• Supports IEEE 802.11a/b/g/n/ac/ax/be
• Supports 2.4GHz/5GHz/6GHz* frequency band
• Supports 160MHz channel bandwidth with 6GHz* frequency band
• 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology
• Supports Bluetooth 5.4
• Supports MU-MIMO

• The Wi-Fi 7 module is supported by Microsoft Windows 11 only. There is no driver available for Windows 10. The availability of the 6GHz band will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows Update and software updates once available.
  Expansion Slots
  CPU:

• 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
• 2 x PCIe 3.0 x16 Expansion Slots (PCIE2 and PCIE3), support x4 mode*
• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
• 15µ Gold Contact in VGA PCIe Slot (PCIE1)

• PCIE1 will run at Gen5x16 with 9000 and 7000 series processors, Gen4x8 with 8000 (Phoenix 1) series processors and Gen4x4 with 8000 (Phoenix 2) series processors.
  If M2_3 is occupied, PCIE2 will downgrade to x2 mode.
  If M2_4 is occupied, PCIE3 will downgrade to x2 mode.
  Supports NVMe SSD as boot disks
  Storage
  CPU:

• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
• 1 x Blazing M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
  Chipset:
• 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
• 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
• 2 x SATA3 6.0 Gb/s Internal I/O Connectorss

• Supports NVMe SSD as boot disks
  M2_1 is the first priority for M.2 installation.
  M2_1 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1 and Phoenix 2) series processors.
  M2_2 will run at Gen5x4 with 9000 and 7000 series processors and Gen4x4 with 8000 (Phoenix 1) series processors. M2_2 will be unavailable with 8000 (Phoenix 2) series processors.
  If M2_2 is occupied, both rear USB4 Type-C Ports and M2_2 will downgrade to x2 mode. You can switch M2_2 to x4 mode in BIOS setting, but doing so will disable USB4_TC1 and USB4_TC2.
  If M2_3 is occupied, PCIE2 will downgrade to x2 mode.
  If M2_4 is occupied, PCIE3 will downgrade to x2 mode.
  RAID

• Supports RAID 0 and RAID 1 for SATA storage devices
• Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
  USB
  CPU:
• 2 x USB4 Type-C (Rear)
• 2 x USB 3.2 Gen1 Type-A (Rear (USB32_1 and USB32_4))
  Chipset:
• 1 x USB 3.2 Gen2x2 Type-C (Front)
• 9 x USB 3.2 Gen1 Type-A (5 Rear (USB32_2, USB32_356, USB32_7), 4 Front))
• 1 x USB 3.2 Gen1 Type-C (Rear)
• 10 x USB 2.0 (6 Rear, 4 Front)

• All USB ports support ESD Protection
  Internal I/O Connectors

• 1 x SPI TPM Header
• 1 x Thermistor Cable Header
• 1 x Power LED and Speaker Header
• 1 x RGB LED Header*
• 3 x Addressable LED Headers**
• 2 x CPU Fan Internal I/O Connectorss (4-pin) (Smart Fan Speed Control)***
• 3 x Chassis Fan Internal I/O Connectorss (4-pin) (Smart Fan Speed Control)***
• 1 x AIO Pump Fan Internal I/O Connectors (4-pin) (Smart Fan Speed Control)***
• 1 x 24 pin ATX Power Internal I/O Connectors (Hi-Density Power Internal I/O Connectors)
• 2 x 8 pin 12V Power Internal I/O Connectorss (Hi-Density Power Internal I/O Connectors)
• 1 x Front Panel Audio Internal I/O Connectors
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
• 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
• 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)

• Supports in total up to 12V/3A, 36W LED Strip
  ** Support in total up to 5V/3A, 15W LED Strip
  *** CPU_FAN1 supports the fan power up to 1A (12W).
  CPU_FAN2, CHA_FAN13 and AIO_PUMP support the fan power up to 3A (36W).
  CPU_FAN2, CHA_FAN13 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
