ASUS MB Sc LGA1851 PRO H810M-C-CSM, 2xDDR5, 1xDP, 1xHDMI, 1xVGA, 1xDVI-D, mATX

ASUS Pro H810M-C-CSM
Micro-ATX H810 business motherboard with enhanced security, reliability, manageability and serviceability

• Ready for Advanced AI PCs: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications
• Intel LGA 1851 Socket: Ready for Intel Core™ Ultra Processors (Series 2)
• ASUS CSM Program: A stable motherboard supply, end-of-life notifications, and IT software for business motherboards
• ASUS Control Center Express: Integrated IT monitoring and management software that simplifies enterprise-level system administration
• Enhanced System Security: Self-recovering BIOS to safeguard PCs
• Consistent and Reliable Performance: High-quality components and rigorous testing to help ensure durability in harsh environments
• Efficient Management and Customization: An event log and commercial BIOS kit to enable easy maintenance
• Better Serviceability: Q-LED Core diagnostic display and COM debug header to facilitate building and support processes
• Ultrafast Connectivity: PCIe 5.0 slot, two PCIe 4.0 M.2 slots, DDR5, rear USB 10Gbps Type-A and Type-C
• DIY Friendly Design: SafeSlot, Dual DIMM clips, Box headers
  CPU
  Supports Intel Core™ Ultra Processors (Series 2), LGA1851*
  Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0**

• Refer to https://www.asus.com/support/download-center/ for CPU support list.
  ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
  Chipset
  Intel H810 Chipset
  Memory
  2 x DIMM slots, max. 128GB, DDR5
  Supports up to 6400MT/s, Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)*
  Dual channel memory architecture
  DIMM Fit
  Supports Intel Extreme Memory Profile (XMP) memory module
  ASUS Enhanced Memory Profile II (AEMP II)
• Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.
• Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
  Graphics
  1 x DisplayPort**
  1 x VGA port
  1 x DVI-D port
  1 x HDMI™ port***
• Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
  ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
  *** Supports 4K@60Hz as specified in HDMI 2.1.
  **** Supports up to 3 displays simultaneously.
  Expansion Slots
  Intel Core™ Ultra Processors (Series 2)
  1 x PCIe 5.0 x16 slot
  Intel H810 Chipset
  2 x PCIe 4.0 x1 slots

• To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.
  Storage
  Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
  Intel H810 Chipset
  M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode)
  4 x SATA 6Gb/s ports
  Ethernet
  1 x Intel 1Gb Ethernet port*
  ASUS LANGuard

• With Intel I219V LAN, Wake-on-LAN is not supported in S5 after the system transitions from G3.
  USB
  Rear USB (Total 6 ports)
  2 x USB 10Gbps ports (1 x Type-A + 1 x USB Type-C)
  2 x USB 5Gbps ports (2 x Type-A)
  2 x USB 2.0 ports (2 x Type-A)
  Front USB (Total 6 ports)
  1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
• USB Type-C power delivery output: max. 5V/3A
  Audio
  Realtek 7.1 Surround Sound High Definition Audio CODEC*

• Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• Supports up to 24-Bit/192 kHz playback

• A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
  Back Panel I/O Ports
  2 x USB 10Gbps ports (1 x Type-A + 1 x USB Type-C)
  2 x USB 5Gbps ports (2 x Type-A)
  2 x USB 2.0 ports (2 x Type-A)
  1 x DisplayPort
  1 x VGA port
  1 x DVI-D port
  1 x HDMI™ port
  1 x Intel 1Gb Ethernet port
  3 x Audio jacks
  1 x COM port
  1 x PS/2 keyboard/mouse combo port
  Internal I/O Connectors
  Fan and Cooling Related
  1 x 4-pin CPU Fan header
  2 x 4-pin Chassis Fan headers
  Power Related
  1 x 24-pin Main Power connector
  1 x 8-pin +12V CPU Power connector
  Storage Related
  2 x M.2 slots (Key M)
  4 x SATA 6Gb/s ports
  USB
  1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
  Miscellaneous
  1 x Clear CMOS header
  1 x Chassis Intrusion header
  1 x COM Port header
  1 x Front Panel Audio header (F_AUDIO)
  1 x COM Debug header
  1 x LPT header
  1 x Mono-Out Audio header (with Amp IC)
  1 x SMBUS header
  1 x Speaker header
  1 x SPI TPM header (14-1 pin)
  1 x 10-1 pin Front Panel System header
  Special Features
  ASUS Q-Design

• Q-LED Core
• Q-Slot
  ASUS Thermal Solution
• Aluminum heatsink design
  ASUS EZ DIY
• Box headers
• Dual DIMM clips
• SafeSlot
  Bespoke Motherboard Design & Business Focused Features
• ASUS Self-Recovering BIOS
• ASUS Event Log
• ASUS Commercial BIOS Kit*
• Anti-moisture coating
• 24/7 reliability
• Overcurrent protection

• Please contact local FAE for Commercial BIOS kit.
  Software Features
  ASUS Exclusive Software
  ASUS DriverHub
  UEFI BIOS
  ASUS EZ DIY

• ASUS CrashFree BIOS 3
• ASUS EZ Flash
• ASUS MyHotkey
  Remote Management Features
  IT Management software supported
• ASUS Control Center Express (ACCE)
  Ready for ASUS DASH LAN Card*
  1 x SMBUS header

• ASUS DASH LAN Card is sold separately.
  BIOS
  256 (128+128) Mb Flash ROM, UEFI AMI BIOS
  Manageability
  WOL by PME, PXE
  Accessories
  Cables
  2 x SATA 6Gb/s cables
  Miscellaneous
  1 x I/O shield
  1 x M.2 anchor package
  Documentation
  1 x ACC Express activation key card
  1 x Quick start guide
  Operating System
  Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)
  Form Factor
  micro-ATX Form Factor
  9.6 inch x 8.75 inch ( 24.4 cm x 22.2 cm )
