ASRock MB Sc LGA1851 H810M-P Gen5, Intel H810, 2xDDR5,1xDP, 1xHDMI, mATX

ASRock H810M-P Gen5
Built to deliver reliable performance with versatile features, perfect for daily tasks
Unique Feature
Superb Productivity

• PCIe Gen5 (Graphics)
• Dual Channel DDR5
  Rock-Solid Durability
• 6+1+1+1+1 Power Phase
  ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology
  EZ Update
• ASRock Auto Driver Installer
  CPU
• Supports Intel Core™ Ultra Processors (Series 2) (LGA1851)
• Supports Intel Hybrid Technology
• Supports Intel Turbo Boost Max 3.0 Technology
• Supports Intel Thermal Velocity Boost (TVB)
• Supports Intel Adaptive Boost Technology (ABT)
• Integrated NPU for dedicated AI acceleration
  Chipset
• Intel H810
  Memory
• Dual Channel DDR5 Memory Technology
• 2 x DDR5 DIMM Expansion Slots
• Supports DDR5 non-ECC, un-buffered memory up to 6400*
• Supports Clocked Unbuffered DIMM (CUDIMM)
• Max. capacity of system memory: 128GB
• Supports Intel Extreme Memory Profile (XMP) 3.0x*
  *Please refer to Memory Support List on ASRock's website for more information.
  BIOS
• 256Mb AMI UEFI Legal BIOS with GUI support
  Graphics
• Intel Xe LPG Graphics Architecture
• 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
  *Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
  Audio
• 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
  LAN
• Gigabit LAN 10/100/1000 Mb/s
• Realtek RTL8111H
  Expansion Slots
  CPU:
• 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
• 1 x PCIe 4.0 x1 Slot (PCIE2)*
• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

• Supports NVMe SSD as boot disks

Storage
Chipset:

• 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
• 4 x SATA3 6.0 Gb/s Internal I/O Connectorss*Supports NVMe SSD as boot disks
  USB
  Chipset:
• 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
• 6 x USB 2.0 (4 Rear, 2 Front)
  *All USB ports support ESD Protection
  Internal I/O Connectors
• 1 x SPI TPM Header
• 1 x Power LED and Speaker Header
• 1 x RGB LED Header*
• 2 x Addressable LED Headers**
• 1 x CPU Fan Internal I/O Connectors (4-pin) (Smart Fan Speed Control)***
• 1 x Chassis Fan Internal I/O Connectors (4-pin) (Smart Fan Speed Control)****
• 1 x 24 pin ATX Power Internal I/O Connectors
• 1 x 8 pin 12V Power Internal I/O Connectors
• 1 x Front Panel Audio Internal I/O Connectors
• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
  *Supports in total up to 12V/3A, 36W LED Strip
  **Support in total up to 5V/3A, 15W LED Strip
  ***CPU_FAN1 supports the fan power up to 1A (12W).
  ****CHA_FAN1 supports the fan power up to 3A (36W).
  CHA_FAN1 can auto detect if 3-pin or 4-pin fan is in use.
  Back Panel I/O Ports
• 2 x Antenna Mounting Points
• 1 x HDMI Port
• 1 x DisplayPort 1.4
• 2 x USB 3.2 Gen1 Ports
• 4 x USB 2.0 Ports
• 1 x RJ-45 LAN Port
• HD Audio Jacks: Line in / Front Speaker / Microphone
  Software and UEFI
  Software
• ASRock Motherboard Utility (A-Tuning)
• ASRock Polychrome SYNC*
  UEFI
• ASRock EZ Mode
• ASRock Full HD UEFI
• ASRock My Favorites in UEFI
• ASRock Auto Driver Installer
• ASRock Instant Flash
  *These utilities can be downloaded from ASRock Live Update & APP Shop.
  Accessories
• 1 x I/O Shield
• 2 x SATA Data Cables
• 1 x Screw for M.2 Socket
  Form Factor
• Micro ATX Form Factor: 9.6-in x 7.6-in, 24.4 cm x 19.3 cm
  OS
• Microsoft Windows 11 64-bit
  Certifications
• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)

Formát základní desky: micro ATX
Chipset: Intel H810
Socket (patice): Socket 1851
Pro procesory: Intel
Technologie paměti RAM: DDR5
Počet paměťových slotů: 2
M.2 slot: 1
SATA 3: 4
Podpora RAID: Bez RAID podpory
PCI Express x16: 1
PCI Express x8: 0
PCI Express x1: 1
PCI: 0
LAN: 1Gbit/s
Bezdrátové připojení: bez
DisplayPort: 1
HDMI: 1
VGA: 0
DVI: 0
