ASRock MB Sc LGA1851 B860M-X, Intel B860, 2xDDR5, 1xDP, 1xHDMI, mATX

ASRock B860M-X
X Series motherboard offers a compact, high-value solution, balancing performance, versatility, and reliability for both professional and daily tasks.
Unique Feature
Superb Productivity

• PCIe Gen5 (M.2)
• Dual Channel DDR5
  Rock-Solid Durability
• 7+1+1+1+1 Power Phase
  Ultrafast Connectivity
• 2.5G LAN
  EZ Update
• BIOS Flashback Button
• ASRock Auto Driver Installer
  EZ Troubleshooter
• ASRock Post Status Checker
  CPU
• Supports Intel Core™ Ultra Processors (Series 2) (LGA1851)
• Supports Intel Hybrid Technology
• Supports Intel Turbo Boost Max 3.0 Technology
• Supports Intel Thermal Velocity Boost (TVB)
• Supports Intel Adaptive Boost Technology (ABT)
• Integrated NPU for dedicated AI acceleration
  Chipset
• Intel B860
  Memory
• Dual Channel DDR5 Memory Technology
• 2 x DDR5 DIMM Slots
• Supports DDR5 non-ECC, un-buffered memory up to 9066+(OC)*
• Supports Clocked Unbuffered DIMM (CUDIMM)
• Max. capacity of system memory: 128GB
• Supports Intel Extreme Memory Profile (XMP) 3.0x
  *1DPC 1R Up to 9066+ MHz (OC), 6400 MHz Natively. 1DPC 2R Up to 6800+ MHz (OC), 6400 MHz Natively.
  BIOS
• 256Mb AMI UEFI Legal BIOS with GUI support
  Graphics
• Intel Xe LPG Graphics Architecture
• 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
  *Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
  Audio
• 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
  LAN
• 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
• Dragon RTL8125BG
• Supports Dragon 2.5G LAN Software
• Smart Auto Adjust Bandwidth Control
• Visual User Friendly UI
• Visual Network Usage Statistics
• Optimized Default Setting for Game, Browser, and Streaming Modes
• User Customized Priority Control
  Slots
  CPU:
• 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
• 1 x PCIe 4.0 x1 Slot (PCIE2)*
• 1 x PCIe 4.0 x4 Slot (PCIE3), supports x4 mode*
• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT)
  *Supports NVMe SSD as boot disks
  Storage
  CPU:
• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode*
  Chipset:
• 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
• 4 x SATA3 6.0 Gb/s Connectors
  *Supports Intel Volume Management Device (VMD)
  Supports NVMe SSD as boot disks
  RAID
• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
  USB
  CPU:
• 1 x USB 3.2 Gen2x2 Type-C (Rear)
  Chipset:
• 1 x USB 3.2 Gen1 Type-C (Front)
• 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front)
• 6 x USB 2.0 (2 Rear, 4 Front)
  *All USB ports support ESD Protection
  Connector
• 1 x SPI TPM Header
• 1 x Power LED and Speaker Header
• 1 x RGB LED Header*
• 2 x Addressable LED Headers**
• 2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***
• 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***
• 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
• 1 x 4 pin 12V Power Connector (Hi-Density Power Connector)
• 1 x Front Panel Audio Connector
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
• 1 x Front Panel Type C USB 3.2 Gen1 Header
  *Supports in total up to 12V/3A, 36W LED Strip
  **Support in total up to 5V/3A, 15W LED Strip
  ***CPU_FAN1 supports the fan power up to 1A (12W).
  CPU_FAN2, CHA_FAN12 and AIO_PUMP support the fan power up to 3A (36W).
  CPU_FAN2, CHA_FAN12 and AIO_PUMP can auto detect if 3-pin or 4-pin fan is in use.
  Rear Panel I/O
• 2 x Antenna Mounting Points
• 1 x HDMI Port
• 1 x DisplayPort 1.4
• 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
• 3 x USB 3.2 Gen1 Ports
• 2 x USB 2.0 Ports
• 1 x RJ-45 LAN Port
• 1 x BIOS Flashback Button
• HD Audio Jacks: Line in / Front Speaker / Microphone
  Software and UEFI
  Software
• ASRock Motherboard Utility (A-Tuning)
• ASRock Dragon 2.5G LAN Software
• ASRock Polychrome SYNC*
  UEFI
• ASRock EZ Mode
• ASRock Full HD UEFI
• ASRock My Favorites in UEFI
• ASRock Auto Driver Installer
• ASRock Instant Flash
  *These utilities can be downloaded from ASRock Live Update & APP Shop.
  Accessories
• 1 x I/O Shield
• 2 x SATA Data Cables
• 2 x Screws for M.2 Sockets
• 1 x Standoff for M.2 Socket
  Form Factor
• Micro ATX Form Factor: 9.6-in x 8.6-in, 24.4 cm x 21.8 cm
  OS
• Microsoft Windows 11 64-bit
  Certifications
• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)

Formát základní desky: micro ATX
Chipset: Intel B860
Socket (patice): Socket 1851
Pro procesory: Intel
Technologie paměti RAM: DDR5
Počet paměťových slotů: 2
M.2 slot: 2
SATA 3: 4
Podpora RAID: 0, 1, 5, 10
PCI Express x16: 1
PCI Express x1: 1
LAN: 2.5Gbit/s
Bezdrátové připojení: bez
DisplayPort: 1
HDMI: 1
VGA: 0
DVI: 0
DisplayPort Type-C: 0
USB 2: 6
