ASRock MB Sc AM5 B650 PG Lightning, AMD B650, 4xDDR5, 1xHDMI

B650 PG Lightning

• Supports AMD Ryzen™ 7000 Series Processors
• 14+2+1 Phase Power Design, SPS
• 4 x DDR5 DIMMs, supports up to 6400+(OC)
• 1 PCIe 4.0 x16, 1 PCIe 4.0 x16, 2 PCIe 4.0 x1, 1 M.2 Key-E for WiFi
• Graphics Output Options: 1 HDMI
• 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio
• 1 Blazing M.2 (PCIe Gen5x4), 1 Hyper M.2 (PCIe Gen4x4), 1 M.2 (PCIe Gen4x2), 4 SATA3
• 1 USB 3.2 Gen2x2 Type-C (Rear), 1 USB 3.2 Gen2 Type-C (Front), 9 USB 3.2 Gen1 (7 Rear, 2 Front), 8 USB 2.0 (4 Rear, 4 Front)
• Realtek 2.5G LAN
  Unique Feature
  Superb Productivity
• PCIe Gen5 (M.2)
• Dual Channel DDR5
  Rock-Solid Durability
• 14+2+1 Power Phase, 60A SPS
• Pre-Installed I/O Shield
  Ultrafast Connectivity
• 2.5G LAN
• ASRock Lightning Gaming Ports
  EZ Update
• BIOS Flashback Button
• ASRock Auto Driver Installer
  EZ Troubleshooter
• ASRock Post Status Checker
  CPU
• Supports AMD Socket AM5 Ryzen™ 7000 Series Processors
  Chipset
• AMD B650
  Memory
• Dual Channel DDR5 Memory Technology
• 4 x DDR5 DIMM Slots
• Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC)*
• Max. capacity of system memory: 128GB*
• Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
  BIOS
• 256Mb AMI UEFI Legal BIOS with GUI support
  Graphics
  Integrated AMD RDNA™ 2 graphics (Actual support may vary by CPU)
• 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
  Audio
• 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
• Nahimic Audio
  LAN
• 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
• Dragon RTL8125BG
• Supports Phantom Gaming LAN Software
• Smart Auto Adjust Bandwidth Control
• Visual User Friendly UI
• Visual Network Usage Statistics
• Optimized Default Setting for Game, Browser, and Streaming Modes
• User Customized Priority Control
  Slots
  CPU:
• 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
• 1 x PCIe 4.0 x16 Slot (PCIE3), supports x2 mode*
• 2 x PCIe 4.0 x1 Slots (PCIE2 and PCIE4)*
• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
• 15µ Gold Contact in VGA PCIe Slot (PCIE1)
  *Supports NVMe SSD as boot disks
  Storage
  CPU:
• 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
• 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  Chipset:
• 1 x M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x2 (32 Gb/s) mode*
• 4 x SATA3 6.0 Gb/s Connectors
  *Supports NVMe SSD as boot disks
  Supports ASRock U.2 Kit
  RAID
• Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
• Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
  *Requires additional M.2 NVMe expansion cards to support RAID 10
  USB
• 1 x USB 3.2 Gen2x2 Type-C (Rear)
• 1 x USB 3.2 Gen2 Type-C (Front)
• 9 x USB 3.2 Gen1 (7 Rear, 2 Front)
• 8 x USB 2.0 (4 Rear, 4 Front)
  *All USB ports support ESD Protection
  Connector
• 1 x SPI TPM Header
• 1 x Power LED and Speaker Header
• 1 x RGB LED Header*
• 3 x Addressable LED Headers**
• 1 x CPU Fan Connector (4-pin)***
• 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
• 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
• 1 x 24 pin ATX Power Connector
• 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
• 1 x Front Panel Audio Connector
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
• 1 x Front Panel Type C USB 3.2 Gen2 Header (ReDriver)
  *Supports in total up to 12V/3A, 36W LED Strip
  **Support in total up to 5V/3A, 15W LED Strip
  ***CPU_FAN1 supports the fan power up to 1A (12W).
  ****CPU_FAN2/WP supports the fan power up to 2A (24W).
  *****CHA_FAN14/WP support the fan power up to 2A (24W).
  CPU_FAN2/WP and CHA_FAN14/WP can auto detect if 3-pin or 4-pin fan is in use.
  Rear Panel I/O
• 2 x Antenna Mounting Points
• 1 x HDMI Port
• 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (ReDriver)
• 7 x USB 3.2 Gen1 Ports (USB32_34 are Lightning Gaming Ports) (USB32_12 and USB32_56 are from ASMedia ASM1074 hub)
• 4 x USB 2.0 Ports
• 1 x RJ-45 LAN Port
• 1 x BIOS Flashback Button
• HD Audio Jacks: Line in / Front Speaker / Microphone
  Software and UEFI
  Software
• ASRock Motherboard Utility (Phantom Gaming Tuning)
• ASRock Phantom Gaming LAN Software
• ASRock Polychrome SYNC*
  UEFI
• ASRock Full HD UEFI
• ASRock Auto Driver Installer
• ASRock Instant Flash
  *These utilities can be downloaded from ASRock Live Update & APP Shop.
  Accessories
• 1 x User Manual
• 2 x SATA Data Cables
• 3 x Screws for M.2 Sockets
  Form Factor
• ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
• 8 Layer PCB
  OS
• Microsoft Windows 10 64-bit / 11 64-bit
  Certifications
• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)

Formát základní desky: ATX
Chipset: AMD B650
Socket (patice): Socket AM5 (LGA 1718)
Pro procesory: AMD
Technologie paměti RAM: DDR5
Počet paměťových slotů: 4
SATA 3: 4
Podpora RAID: 0, 1, 10
PCI Express x16: 2
PCI Express x1: 2
DisplayPort: 1
HDMI: 0
VGA: 0
DVI: 0
TPM
3.5mm Jack
